UP2

UP2

Regular price $1,399.99
/
Shipping calculated at checkout.

PROVEN SUSPENSION AND VALUE


BUILT FOR COMFORT & CONTROL.

The UP2 full suspension MTB nails it with performance and value better than any other bike in its category. Hydraulic brakes and a 1x drivetrain provide the exact stop and go specifications needed for all-mountain riding. Dual suspension gives the rider all around comfort and precision handling on the roughest trails. 120/150mm of travel make it the ideal ride for the someone who want a capable mountain bike for shredding gnar.

  • Light Weight Aluminum Alloy Frame, 120mm Front Suspension, Rear Hydraulic Air Shock 150mm
  • Double wall 6-Bolt Aluminum thru-axle wheels
  • Hydraulic Disc Brakes
  • L-Twoo 1x widerange gearing
  • Limited lifetime warranty on frame




KEY FEATURES


OFF ROAD CONTROL

2.1" tires have excellent traction, grip, and control while riding off road.



SOLID PERFORMANCE

Solid performance in a no fuss 1x set up that gives you a wide enough range to tackle the biggest hills up or down.



4" of FULL SUSPENSION TRAVEL

Infinitely adjustable air sprung rear suspension mated to a Suntour SR XCM 120mm front fork give you control and the capability you need.




PRODUCT SPECS


Sizes S, M, L, XL Chain
KMC 10s
Color Black Pedals
Platform 9/16"
Frame Alloy, 29", disc, BC 24x1.37", rear suspension, 12X142MM Handle bars
Alloy, 720mm
Fork Alloy, 29", disc, 120mm w/lockout, 12X100MM
Stem
Alloy 31.8mm
Wheel set
Alloy, double wall, 6-bolt, cassette, 32h 120mm Head set
Threadless
Tires
29x2.1" Grips/ Tape
Black
Shifters/ Brake Levers
L-TWOO A7 1x10s
Brake set
Tecktro hydraulic 160mm
Front Derailleur
N/A
Saddle
Black
Rear Derailleur
L-TWOO A7 Seatpost/ Clamps
Alloy 31.6mm
Crank set 36t
Extras --
Bottom Bracket
Sealed Cartridge  Weight/ Weight Limit
--
Cassette
10s 11-46t
Manufactures Warranty
--
Specs are subject to change without notice


SIZING GUIDE


BIKE GEOMETRY



Bike Sizes S M L XL
ST - Seat Tube Length 420
460
510
560
TT - Horizontal TT length 570.4
590.3
609.6
629.5
ST° - Seat Angle 68.7°
68.7° 68.7° 68.7°
HT° - Head Angle 68° 68° 68° 68°
HT - Head Tube Length 120
125
180
185
BB - BB Drop 20
20 20 20
CS - Chainstay Length 450
450 450 450
FO - Fork Offset 39 39 39 39
TR - Trail 95
95 95 95
WB - Wheelbase Length 1127.2 1147 1167
1187
SO - Standover (center tt - ground) 830
815
822
853
RH - Reach 411.1
429.3
428.7
446.7
SK - Stack 575.6
580.3
631.2
635.9
FL - Fork Length
495
495
495
495
All measurements are provided in millimeters (mm) unless indicated otherwise
