E-Terrain

E-Terrain

Regular price $3,799.99
/
Shipping calculated at checkout.

ELECTRIFY YOUR RIDE


The E-Terrain is our take on a sporty do it all road bike. Wide tires provide comfort over gravel roads and city streets and flat handlebars put you more upright to take in the views and stay vigilant of other road users on your commute. The integrated mid-drive 200 watt motor and 36V battery can take you from a ride across to riding to the next town. Disc brakes provide the secure and powerful stopping ability needed for an eBike.


  • Light weight Aluminum alloy frame and fork, geometry built around ride stability and comfort
  • 700c Double Wall Aluminum 6-bolt wheels
  • Disc brakes
  • Shimano Tiagra shifting system
  • Limited lifetime warranty on frame





KEY FEATURES


WIDE AND SUPPLE 40MM WIDE TIRES

Provide excellent comfort, grip, and control while riding off-road.



ALUMINUM FRAME



Aluminum frame and fork provide the perfect combination of low weight and high vibration dampening.



INTEGRATED BATTERY

Integrated battery provides a very slick look.




PRODUCT SPECS


Sizes 51/54/57 Chain
KMC X10
Color Bronze Pedals
Platform 9/16"
Frame Alloy, 700c, disc, BC 1.37x24t, QR Handle bars
Alloy, 660*31.8mm, Flat
Fork Alloy, 700c, Disc, QR Stem
Alloy, 70mm
Wheel set
Alloy 700c, Double Wall, 36H, Cassette, 6B Disc Head set
Threadless 1 1/8"
Tires
Kenda 700x42c Grips/ Tape
Black, Rubber
Shifters/ Break Levers
Shimano Tiagra 4700 10s Trigger, Tektro Brake set
Tektro Mechanical Disc brake w/ 160mm rotor
Front Derailleur
N/A Saddle
Adult
Rear Derailleur
Shimano Tiagra 4700 10s Seatpost/ Clamps
Alloy, 30.9*350mm
Crank set 44t, 170mm Extras N/A
Bottom Bracket
Intergrated w/ Motor, Sealed Cartridge Weight/ Weight Limit
--
Cassette
Shimano HG500 10s, 12-28T Manufactures Warranty
Frame: Lifetime, Parts & Components: 1 year
Specs are subject to change without notice

E-BIKE COMPONENT SPECS


Motor Brand Bafang  Battery Chemistry
Lithium-ion
Motor Type
Mid-drive
Charge time
6 Hours
Motor Nominal Output
200W
Estimated Min Range
25 Miles
Motor Peak Output
--
Estimated Max Range
35 Miles
Motor Torque
55N.m
Display Type
LCD
Battery Brand
Greenway Readouts
Battery level, motor output, assistance level, speed, trip and total distance, trip time
Battery Voltage
36V
Display Accessories
LCD-DP-260
Batter Amps
10.4Ah
Drive Mode
5 levels
Battery Watt Hours
374Wh
Top Speed
20 MPH

SIZING GUIDE


BIKE GEOMETRY



Bike Sizes S
M
L
ST - Seat Tube Length 510 540
570
TT - Horizontal TT length 623
608
627
ST° - Seat Angle 73° 73° 73°
HT° - Head Angle 70° 70° 70°
HT - Head Tube Length 185
185
185
BB - BB Drop 70
70
70
CS - Chainstay Length 490
490
490
FO - Fork Offset 46
46
46
TR - Trail --
--
--
WB - Wheelbase Length 1171
1153
1171
SO - Standover (center tt - ground) 820
833
849
RH - Reach 436
419
436
SK - Stack 623
620
623
FL - Fork Length
420
420
420
All measurements are provided in millimeters (mm) unless indicated otherwise
